PVC Conveyor System

Name: PVC Conveyor System
Brand: KAYA TECHNOLOGY
Price: 25000.0 INR
Availability: InStock

Price 25000.0 INR/ Kilovolt

Get a Price/Quote

MOQ : 1 Piece

PVC Conveyor System Specification

Features
Easy installation, low maintenance, lightweight design

Surface Finish
Smooth finish

Power Source
Electric

Thickness
2 mm - 5 mm PVC belt

Belt Type
Plain PVC, Green/White

Material
PVC belt, MS / SS structure

Type
PVC Conveyor System

Structure
Mild steel frame / Stainless steel frame

Belt Conveyor
Yes

Roller Conveyor
Optional / Compatible

Vertical Conveyor
Available upon request

Pneumatic Conveyor
Not Included

Resistant Feature
Corrosion resistant, abrasion resistant

Load Capacity
50-200 kg per meter

Voltage
220 V / 380 V, 3 phase

Power
0.75 - 3 kW

Speed
0.5 - 2 m/s (adjustable)

Usage & Applications
Food, packaging, assembly, pharmaceuticals, logistics, warehouses

Drive Type
Motorized drum / Geared motor

Operating Temperature
-10C to +60C

Length
2 m - 20 m (customizable)

Customization
Conveyor dimensions and specifications are customizable as per requirement

Belt Width
300 mm - 1200 mm

Noise Level
Low noise operation

Installation
On-site installation available

Support Legs
Adjustable height support legs

Safety Features
Side guards and emergency stop switch

About PVC Conveyor System

A PVC Belt Conveyor System is a material handling equipment used for transporting goods efficiently from one location to another within industrial environments. The conveyor consists of a continuous PVC (Polyvinyl Chloride) belt mounted over rollers and driven by a motorized system.

This type of conveyor is widely used in industries such as packaging, food processing, pharmaceuticals, logistics, and manufacturing due to its smooth operation, durability, and low maintenance.

Customizable Solutions for Diverse Needs

Our PVC Conveyor System can be configured with a wide range of belt widths, lengths, and features, making it suitable for various industries. Choose from different drive types, support structures, and frame materials to build a system that matches your workflow. We also offer on-site installation and precise customization to your required specifications, ensuring seamless integration into your operations.

Engineered for Durability and Safety

Built with corrosion and abrasion resistant materials, the conveyor system guarantees long service life even in demanding environments. Safety is prioritized with side guards and an emergency stop switch. The smooth PVC belt is easy to clean, making it ideal for food and pharmaceutical usage. Adjustable support legs and low noise operation further enhance operational efficiency.

Seamless Performance and Low Maintenance

With a reliable electric power source, efficient geared motors, and adjustable speeds from 0.5 to 2 m/s, this conveyor minimizes downtime. The lightweight yet robust design ensures easy installation and relocation. Designed for low maintenance, the conveyor supports high load capacity ranges, enabling continuous, smooth operation for warehousing, distribution, and manufacturing.

FAQ's of PVC Conveyor System:

Q: How can I customize the PVC Conveyor System to fit my application?

A: You can specify the required belt width, length, height, and drive type to suit your workflow. Additional customization options include belt color, surface finish, support leg height, and frame material. Our team will help design the conveyor to match your operational needs, ensuring optimal efficiency.

Q: What is the installation process for the conveyor system?

A: We offer on-site installation services across India. Our technicians will set up the system, adjust the support legs for desired height, and ensure proper alignment. After installation, a safety check and trial run are conducted for smooth operation and staff training if required.

Q: Where can this conveyor system be used effectively?

A: This conveyor is ideal for food processing, packaging lines, assembly areas, pharmaceutical plants, logistics operations, and warehouses. Its corrosion and abrasion resistance make it suitable for both dry and humid environments within the operating temperature range of -10C to +60C.

Q: What safety features does the PVC Conveyor System include?

A: The system is equipped with side guards to prevent materials from falling off and an emergency stop switch for rapid shutdown in case of emergencies. These features ensure safe operations for personnel working near the conveyor.

Q: How much load can the conveyor handle?

A: Each meter of the conveyor can support between 50 kg and 200 kg, depending on the chosen configuration. Please share your material handling requirements for an accurate assessment and customization as needed.

Q: What benefits does this conveyor system offer for daily operations?

A: The system's low noise, easy installation, and low maintenance design boost productivity and minimize operational interruptions. Adjustable speed and height, durable components, and compliance with safety standards foster a reliable and efficient work environment.

Q: Is vertical or roller conveyor integration possible with this system?

A: Yes, vertical conveyors are available on request and our PVC belt conveyor supports compatibility with optional roller conveyors. Let us know your specific requirements to discuss integration possibilities and tailor your material handling solution.
