SS 304 Coconut Shell Washing Conveyor

Name: SS 304 Coconut Shell Washing Conveyor
Brand: KAYA TECHNOLOGY
Price: 200000.0 INR
Availability: InStock

Price 200000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

SS 304 Coconut Shell Washing Conveyor Specification

Surface Finish
Mirror / Matt Finish

Belt Type
Modular Plastic/PU Food Grade Belt

Thickness
2 mm (main conveyor frame)

Features
High durability, hygienic washing, low maintenance, efficient cleaning

Power Source
Electric

Material
SS 304 Stainless Steel

Type
Washing Conveyor

Structure
Stainless Steel Frame

Belt Conveyor
Yes

Roller Conveyor
No

Vertical Conveyor
No

Pneumatic Conveyor
No

Resistant Feature
Corrosion resistant

Load Capacity
Up to 300 kg/hr (customizable)

Voltage
220-415 V

Power
1.5 kW

Speed
Adjustable (0.5 - 3 m/min)

Usage & Applications
Coconut shell cleaning and washing in food processing units

Safety
Emergency Stop Button

Drive Type
Geared Motor Drive

Width
450 mm (customizable)

Conveyor Operation
Continuous

Cleaning System
Water Spray Nozzles with Drainage

Height
850 mm (adjustable)

Noise Level
Less than 75 dB

Length
Available from 3 to 10 meters

Water Consumption
Approx. 100-200 L/hr

About SS 304 Coconut Shell Washing Conveyor

he Coconut Shell Washing Conveyor is a continuous washing system that removes dirt, pith, fibers, dust, mud, and other impurities from coconut shells. The machine typically consists of a stainless steel conveyor belt or screw conveyor integrated with high-pressure water spray nozzles for thorough cleaning.

As the coconut shells move along the conveyor, they are sprayed and agitated to ensure complete washing. The cleaned shells are then discharged for further processing such as drying, crushing, carbonizing, or grinding.

Superior Cleaning Performance

This coconut shell washing conveyor comes equipped with powerful water spray nozzles and an efficient drainage system, guaranteeing thorough removal of contaminants from each shell. The system's robust motor and adjustable speed allow for precise and continuous cleaning, maintaining high productivity while protecting coconut quality.

Customizable for Various Operations

Manufactured from durable SS 304 stainless steel, the conveyor's length, width, height, and load capacity can be tailored to operational needs. Its modular belt design, combined with an adjustable working height, makes it easy to integrate into different food processing setups in India and abroad.

Safety and Maintenance Advantages

The conveyor features an emergency stop button for enhanced operator safety and a corrosion-resistant frame for lasting durability. Designed for low maintenance and hygienic operation, its construction supports swift cleaning and reduced downtime, ensuring reliable use in demanding environments.

FAQ's of SS 304 Coconut Shell Washing Conveyor:

Q: How does the SS 304 Coconut Shell Washing Conveyor ensure effective cleaning of coconut shells?

A: The conveyor uses strategically placed water spray nozzles that thoroughly wash coconut shells as they move along the belt. Combined with a dedicated drainage system, this ensures all debris and contaminants are efficiently removed.

Q: What materials and construction make this conveyor ideal for food processing?

A: The primary structure is built from SS 304 stainless steel, renowned for its corrosion resistance and hygienic properties. The belt is made of modular plastic or PU food-grade material, making it safe for handling coconut shells in food environments.

Q: When is the best stage to use this conveyor in coconut processing?

A: This conveyor is typically used immediately after coconut shells are separated and before any further processing, ensuring that only clean shells advance to the next stage in the production line.

Q: Where can this conveyor be utilized?

A: It is suitable for a variety of food processing units, particularly coconut-based product manufacturers, and integrates seamlessly into existing conveyor systems within factories and agro-industrial operations across India.

Q: What is the operating process for loading and cleaning using this conveyor?

A: Coconut shells are fed onto the belt, which moves them steadily through the cleaning zone, where water spray nozzles wash the shells. The drainage system collects wastewater, and cleaned shells exit at the end of the conveyor. Speed and height can be adjusted as per operational requirements.

Q: How is the water consumption optimized during operation?

A: The system uses approximately 100-200 liters of water per hour, with water spray nozzles ensuring efficient use while maintaining effective cleaning and minimizing water wastage.

Q: What are the key benefits of using this washing conveyor for coconut shells?

A: Key benefits include enhanced hygiene, consistent cleaning, adjustable speed and height, low noise operation, safety features like the emergency stop, corrosion resistance, and minimal maintenance requirements, delivering reliable and cost-effective performance.
